MOONDROP RAYS Gaming IEMs

MOONDROP RAYS USB-C DSP Pro Gaming IEMs

Dual Driver | Hi-Fi Gaming Earphones with AI Mic Noise Cancellation

Description

The MOONDROP RAYS is a next-generation professional gaming earphone featuring a hybrid dynamic and planar magnetic driver configuration, USB-C lossless DSP transmission, and AI-powered noise-canceling microphone. Co-tuned by professional players and HiFi engineers, it offers fully customizable tuning through parametric EQ and presets for popular games like VALORANT and CS:GO. Designed for esports and music lovers alike, the RAYS sets a new standard for immersive audio and competitive advantage.

Features

• Hybrid Drivers: 10mm Sapphire-Plated Dynamic + 6mm Planar Magnetic for ultra-wide frequency response and fast transient reproduction.

• USB-C DSP Audio Card: Integrated DSP with built-in EQ memory and high-resolution decoding up to 32-bit/384kHz.

• AI Denoise Microphone: Embedded NPU enhances vocal clarity, outperforming traditional ENC.

• Professional Game Tuning: Preset and downloadable tuning from pro players for over 20 popular titles.

• Web & App Tuning: Parametric EQ, Auto EQ, filter customization via browser and mobile app.

• HiFi Acoustic Engineering: Full link ultra-low distortion with VDSF Target response for music and gaming excellence.

• Ergonomic Design: Medical-grade 3D printed cavity ensures long-term comfort and acoustic precision.

• Driverless Plug-and-Play: Compatible with phones, tablets, PCs, and consoles via USB-C.

Specifications

• Model: MOONDROP RAYS

• Driver Configuration: 10mm Sapphire-Plated Dynamic + 6mm Planar

• Impedance: 30Ω ±15% (@1kHz)

• Sensitivity: 120dB/Vrms (@1kHz)

• Frequency Range: 7Hz–39kHz

• Effective Response: 20Hz–20kHz (IEC60318-4, -3dB)

• THD+N: ≤0.05% (@1kHz)

• Connector: 0.78mm 2-pin

• Plug: USB-C
